China Geomembrane HDPE Liners
Manufactured from premium polymers including HDPE, LDPE, PVC and EPDM
Excellent chemical resistance and impermeability
Superior tensile strength and puncture resistance
UV-stabilized formulations for outdoor applications
China Geomembrane HDPE Liners
China geomembrane HDPE liners are premium-grade impermeable barriers manufactured from high-density polyethylene resin. These engineered liners are widely recognized as the most durable and cost-effective containment solution for critical environmental and industrial applications.Due to the addition of auxiliary materials such as anti-aging agents,Smooth geomembrane can maintain its stable performance for a long time and extend its service life.
China geomembrane HDPE liners are synthetic membrane liners or barriers manufactured from polymeric materials, designed to control fluid migration in various engineering and environmental applications. These high-performance materials serve as critical containment solutions where impermeability and durability are essential.
China Geomembrane HDPE Liners
|
Item
|
HDPE Geomembrane Technical Data
|
||||||||
|
Thickness mm
|
0.30
|
0.50
|
0.75
|
1.00
|
1.25
|
1.50
|
2.00
|
2.50
|
3.00
|
|
Density g/cm3
|
>=0.940
|
||||||||
|
Tensile yield strength(TD/MD)
|
≥4
|
≥7
|
≥10
|
≥13
|
≥16
|
≥20
|
≥26
|
≥33
|
≥40
|
|
Tensile Strength at Break(TD/MD)
|
≥6
|
≥10
|
≥15
|
≥20
|
≥25
|
≥30
|
≥40
|
≥50
|
≥60
|
|
Elongation at Yield(TD/MD)
|
_
|
_
|
_
|
≥11
|
|||||
|
Puncture Strength(N)
|
≥72
|
≥120
|
≥180
|
≥240
|
≥300
|
≥360
|
≥480
|
≥600
|
≥720
|
|
Elongation (TD/MD)
|
≥600
|
||||||||
|
Oxidation Induction Time(min)
|
≥60
|
||||||||
|
Water vapor permeability coefficient
( g*cm/(cm*s*Pa))
|
≤1.0×10-13
|
||||||||
|
Dimensional Stability
|
±2.0
|
||||||||
China geomembrane HDPE liners serve as essential engineering solutions across multiple industries, providing reliable containment and protection in demanding environments:
- Salt industry
Salt farm crystallization Pond, collection Pond.
- Oil and Gas
Chemical plant, refinery, oil storage tank etc.
- Solid or liquid waste treatment
Landfill, waste water plant, industrial or hospital waste treatment site anti-seepage
- Water conservancy Project: River
Embankment, lake Dam, tailing dam, sewage dam and reservoir channel, Vertical wall, slope protection seepage contra
- Aquaculture
Sea water or fresh water shrimp or fish farming pond.
- Mining
Washing Pond, heap leaching pond,ash field, dissolving and sedimentation Pond, tailing bottom lining etc.
- Landscaping
River, Reservoir, artificial lake, golf course pond waterproofing, artificial grass waterproof and moisture-proof.
China Geomembrane HDPE Liners
Thickness is a critical parameter for an HDPE geomembrane, balancing strength, cost, and application needs.
- 0.3mm,0.5mm,0.75mm
Seawater and freshwater farms,River dikes, lake dams, tailings dams, sewage dams and reservoirs, channels
- 1mm,1.5mm,2mm,2.5mm,3mm
Landfill,Subway, basement and tunnel and tunnel impermeable lining
Professional geomembrane testing equipments & strict quality control.
Has undertaken domestic and overseas projects for more than 15 years.
Good quality geomembrane approved by many third- party testing organizations, such as SGS, BV.
Products distributed to more than 120 countries around the world.
Dingkun Comapny abides by production quality control procedures and testing standards strictly.In addition,the company are cooperating with internationally renowned raw material suppliers instead of any recycled materials,to guarantee the highest quality geomembrane product with scientific formula.
Dingkun geosynthetics has established advancing laboratory in China for internal inspecting. We founded strict quality control system from raw material to finished products testing.
