Geomembrane Pool
Material:HDPE/LDPE/PVC/EPDM/TPO/LLDPE
Thickness: 0.3mm,0.5mm,0.75mm,1.0mm,1.5mm,2.0mm,3.0mm
Roll Width: 1m,2m,3m,4m,5.8m,6m,7m,8m
Roll Length: 50m,100m,150m,200m
Surface: Smooth,Textured
Colors: Black,Blue,Green,White
Geomembrane Pool
The geomembrane pool engineered for exceptional durability and chemical resistance, they serve as reliable fluid and vapor barriers in a wide range of civil, environmental, and geotechnical applications. Our geomembranes are designed to provide long-term, cost-effective containment solutions for even the most demanding projects.
geomembrane pool
Exceptional Impermeability: Provides an absolute barrier to liquids, vapors, and gases, protecting soil and groundwater from contamination.
Outstanding Chemical Resistance: Withstands exposure to a wide range of aggressive chemicals, leachates, and hydrocarbons.
High Tensile Strength and Puncture Resistance: Engineered to withstand installation stresses, subgrade conditions, and long-term loads.
UV and Weathering Stability: Formulated with carbon black or other additives to resist degradation from sunlight and extreme temperatures for decades.
Flexibility and Conformability: Adapts to subgrade contours and settles without compromising integrity.
geomembrane pool
Waterproofing & Tear Resistance: The geomembrane offer excellent waterproofing, effectively preventing water leakage,ensures the preservation of water resources;also boast outstanding tear resistance,capable of withstanding mechanical stress and ground movements. This reduces the frequency of repairs and replacements, enhancing system reliability and cost-effectiveness.
Safeguard Your Pond: By laying down a reliable Leak-proof pond liners, you not only minimize soil buildup but also fortify your outdoor pond against the intrusion of harmful soil contaminants.
Flexibility & Easy to Use: This large water garden liner underlayment is flexible and soft,enabling effortless customization to fit various shapes and sizes of ponds or water features,allowing for precise trimming without the risk of tearing or damage, ensuring convenient installation and seamless integration into landscaping projects.
The Specifications of Geomembrane Pool
|
Item
|
Index
|
||||||||
|
Thickness (mm)
|
0.30
|
0.50
|
0.75
|
1.00
|
1.25
|
1.50
|
2.00
|
2.50
|
3.00
|
|
Density ( g/cm3)
|
≧0.940
|
||||||||
|
Tensile yield strength (N/mm)
|
≧4
|
≧7
|
≧10
|
≧13
|
≧16
|
≧20
|
≧26
|
≧33
|
≧40
|
|
Tensile fracture strength (N/mm)
|
≧6
|
≧10
|
≧15
|
≧20
|
≧25
|
≧30
|
≧40
|
≧50
|
≧60
|
|
Elongation at yield (%)
|
_
|
_
|
_
|
≧11
|
|||||
|
Elongation at break (%)
|
≧600
|
||||||||
|
Right-angle tear load (N)
|
≧34
|
≧56
|
≧84
|
≧115
|
≧140
|
≧170
|
≧225
|
≧280
|
≧340
|
|
Puncture strength (N)
|
≧72
|
≧120
|
≧180
|
≧240
|
≧300
|
≧360
|
≧480
|
≧600
|
≧720
|
|
Carbon black content (%)
|
2.0~3.0
|
||||||||
The Applications of Geomembrane Pool
Environmental Protection:
Landfill base liners and final caps
Wastewater and evaporation pond liners
Secondary containment for industrial facilities
Water Management:
Potable water reservoirs and irrigation canals
Decorative lakes, ponds, and aquaculture liners
Flood control and stormwater management
Mining & Energy:
Heap leach pads, tailings dams, and process solution ponds
Lining for brine ponds and oil/gas exploration sites
Civil & Infrastructure:
Tunnel and underground waterproofing
Highway and railway sub-grade protection
geomembrane pool
geomembrane pool
geomembrane pool
geomembrane pool
Geomembrane Pool
HDPE (High-Density Polyethylene): The industry standard for its excellent chemical resistance, high tensile strength, and durability. Ideal for landfills, reservoir liners, and mining leach pads.
LLDPE (Linear Low-Density Polyethylene): Offers superior flexibility, elongation, and stress crack resistance. Excellent for applications requiring conformance to uneven subgrades.
PVC (Polyvinyl Chloride): Highly flexible and seamable, perfect for potable water reservoirs, canal linings, and wastewater lagoons.
TPO (Thermoplastic Polyolefin) & fPP (flexible Polypropylene): Provide an excellent balance of chemical resistance, UV stability, and flexibility. Often used in exposed applications and decorative water features.
EPDM (Ethylene Propylene Diene Monomer): A rubber-like membrane known for its outstanding weathering and UV resistance, commonly used in cover systems.
geomembrane pool
geomembrane pool
