Geomembrane Installation
Thickness: Smooth surface 0.2mm-3.0mm, textured surface 1.0mm-2.0mm
Width: Smooth surface 1m-8m, textured surface 4m-8m
Length: 30m-200m/roll or as requested
Material: HDPE, LDPE, LLDPE
Color: Black, blue, white, green
Surface: Smooth surface, single surface textured,dual surfaces textured
Geomembrane Installation
Geomembranes are synthetic membrane liners and barriers manufactured from high-density polyethylene (HDPE), linear low-density polyethylene (LLDPE), or polyvinyl chloride (PVC). Designed with exceptional impermeability and durability, our geomembranes provide reliable containment solutions for environmental, hydraulic, and industrial applications. They are engineered to resist harsh chemicals, UV radiation, and mechanical stress, ensuring long-term performance and environmental safety.
Geomembrane Installation
Advantages of Geomembrane Installation:
Impermeable Barrier: Provides a near-absolute barrier against liquids (water, leachate, chemicals) and gases (methane, vapor).
Containment & Isolation: Prevents pollutants from contaminating soil and groundwater; also preserves valuable resources like water.
Protection: Shields underlying structures and soils.
Durability: Resistant to chemicals, UV radiation, weathering, and biological degradation for decades-long service life.
Geomembrane Installation
HDPE (High-Density Polyethylene):
The Premium Choice. Excellent chemical resistance, high UV stability, and superior tensile strength. Ideal for demanding applications like landfills, mining, and large reservoirs.
LLDPE (Linear Low-Density Polyethylene):
Flexible & Conformable. Offers high elongation and excellent stress crack resistance. Perfect for projects requiring adaptability to uneven subgrades, such as decorative ponds, aquaculture, and secondary containment.
PVC (Polyvinyl Chloride):
Versatile & Cost-Effective. Highly flexible and easy to weld. Commonly used in water conservation (canals, ponds), landfill caps, and tank liners.
The Specifications of Geomembrane Installation
|
Item
|
Index
|
||||||||
|
Thickness (mm)
|
0.30
|
0.50
|
0.75
|
1.00
|
1.25
|
1.50
|
2.00
|
2.50
|
3.00
|
|
Density ( g/cm3)
|
≧0.940
|
||||||||
|
Tensile yield strength (N/mm)
|
≧4
|
≧7
|
≧10
|
≧13
|
≧16
|
≧20
|
≧26
|
≧33
|
≧40
|
|
Tensile fracture strength (N/mm)
|
≧6
|
≧10
|
≧15
|
≧20
|
≧25
|
≧30
|
≧40
|
≧50
|
≧60
|
|
Elongation at yield (%)
|
_
|
_
|
_
|
≧11
|
|||||
|
Elongation at break (%)
|
≧600
|
||||||||
|
Right-angle tear load (N)
|
≧34
|
≧56
|
≧84
|
≧115
|
≧140
|
≧170
|
≧225
|
≧280
|
≧340
|
|
Puncture strength (N)
|
≧72
|
≧120
|
≧180
|
≧240
|
≧300
|
≧360
|
≧480
|
≧600
|
≧720
|
|
Carbon black content (%)
|
2.0~3.0
|
||||||||
Geomembrane Installation’s Applications
Environmental Protection
Secure Landfill Systems: Composite liner systems with leak detection
Contaminated Site Remediation: Vertical barriers and capping systems
Leachate Collection: Integrated with drainage geocomposites
Water Resource Management
Agricultural Water Conservation: Irrigation canals and storage ponds
Aquaculture Operations: Fish and shrimp pond liners
Mining & Energy
Heap Leach Pads: Chemical-resistant formulations
Tailings Management: Reinforced systems for settlement accommodation
Oil & Gas: Secondary containment and brine pond liners
Civil Infrastructure
Tunnel Waterproofing: Prefabricated membrane systems
Green Infrastructure: Stormwater management and rainwater harvesting
Industrial Facilities: Spill prevention and chemical storage
Geomembrane Installation
Geomembrane Installation
Geomembrane Installation
Geomembrane Installation
Geomembrane installation has extremely low permeability, which can effectively prevent the penetration of water and other liquids,ensuring the stability and safety of engineering structures.
The material can withstand the erosion of a variety of chemical substances,including acids, alkalis, salts, etc., and is suitable for various complex environments.
Geomembrane installation has high tensile strength and elongation at break, can withstand large stress and deformation,and is not easy to break.
Due to the addition of auxiliary materials such as anti-aging agents,Smooth Geomembrane can maintain its stable performance for a long time and extend its service life.
