Geomembrane Containment Liner
Material:HDPE/LDPE/PVC/EPDM/TPO/LLDPE
Thickness: 0.3mm,0.5mm,0.75mm,1.0mm,1.5mm,2.0mm,3.0mm
Roll Width: 1m,2m,3m,4m,5.8m,6m,7m,8m
Roll Length: 50m,100m,150m,200m
Surface: Smooth,Textured
Colors: Black,Blue,Green,White
Geomembrane Containment Liner
Geomembranes are high-performance synthetic liners and barriers manufactured from premium polymer materials. Designed with extremely low permeability, they provide reliable fluid and gas containment for critical environmental, industrial, and civil engineering applications. The geomembrane containment liner deliver proven performance in the most demanding containment scenarios while ensuring long-term environmental protection.
geomembrane containment liner
Superior Impermeability
Creates an absolute barrier against liquids, vapors, and gases
Effective containment of leachate, chemicals, and contaminated fluids
Enhanced Durability
Chemical Resistance: Excellent resistance to acids, alkalis, oils, and industrial chemicals
UV Stability: Formulated with carbon black/UV stabilizers for extended outdoor service life
Puncture & Tear Resistance: High tensile strength and elongation properties
geomembrane containment liner
HDPE (High-Density Polyethylene): Superior chemical resistance, ideal for landfills and mining
LLDPE (Linear Low-Density Polyethylene): Enhanced flexibility and conformability
PVC (Polyvinyl Chloride): Excellent seam strength and flexibility for decorative ponds
TPO (Thermoplastic Polyolefin): Balanced chemical resistance and UV stability
EPDM (Ethylene Propylene Diene Monomer): Superior weathering resistance for exposed applications
The Specifications of Geomembrane Containment Liner
|
Item
|
Index
|
||||||||
|
Thickness (mm)
|
0.30
|
0.50
|
0.75
|
1.00
|
1.25
|
1.50
|
2.00
|
2.50
|
3.00
|
|
Density ( g/cm3)
|
≧0.940
|
||||||||
|
Tensile yield strength (N/mm)
|
≧4
|
≧7
|
≧10
|
≧13
|
≧16
|
≧20
|
≧26
|
≧33
|
≧40
|
|
Tensile fracture strength (N/mm)
|
≧6
|
≧10
|
≧15
|
≧20
|
≧25
|
≧30
|
≧40
|
≧50
|
≧60
|
|
Elongation at yield (%)
|
_
|
_
|
_
|
≧11
|
|||||
|
Elongation at break (%)
|
≧600
|
||||||||
|
Right-angle tear load (N)
|
≧34
|
≧56
|
≧84
|
≧115
|
≧140
|
≧170
|
≧225
|
≧280
|
≧340
|
|
Puncture strength (N)
|
≧72
|
≧120
|
≧180
|
≧240
|
≧300
|
≧360
|
≧480
|
≧600
|
≧720
|
|
Carbon black content (%)
|
2.0~3.0
|
||||||||
The Applications of Geomembrane Containment Liner
Geomembrane is widely used: landfill liners, fish ponds in aquaculture, lining of shrimp ponds, agricultural reservoirs, artificial lakes, reservoirs, seepage prevention in chemical plants, tailings, construction projects, etc. Geomembrane is a continuous flexible film made of polymer synthetic materials with excellent waterproof and isolation properties.
Environmental Protection
Landfill Liners & Caps: Primary and secondary containment systems
Heap Leach Pads: Mining solution containment and collection
Contaminated Site Remediation: Isolating polluted soils and groundwater
Water Management
Potable Water Reservoirs: Drinking water storage and protection
Agricultural Ponds: Irrigation storage, aquaculture, and anaerobic digesters
Decorative Water Features: Ponds, lakes, and landscape water elements
Industrial & Civil Engineering
Secondary Containment: Chemical plants, fuel storage, and industrial facilities
Tunnel & Underground Waterproofing: Moisture barriers in infrastructure projects
Canals & Channels: Water conveyance efficiency and seepage prevention
geomembrane containment liner
geomembrane containment liner
geomembrane containment liner
geomembrane containment liner
Geomembrane Containment Liner
Ultimate Impermeable Barrier: Ensures effective containment of liquids, vapors, and gases.
Exceptional Durability: Formulated for superior resistance to ultraviolet (UV) radiation, chemicals, punctures, and extreme temperatures.
Long-Term Stability: Even in exposed or demanding conditions, minimizing lifecycle costs.
Proven Seam Integrity: Engineered for reliable field seaming using thermal methods, creating monolithic, high-strength barriers.
Versatile Material Science: Available in various polymer types (HDPE, LLDPE, PVC, TPO, EPDM) to match specific project chemical, mechanical, and environmental requirements.\
