Geomembrana Para Estanques
Quality Standard: ASTM-GRI GM13
Thickness: 0.1mm,0.2mm,0.3mm,0.5mm,0.75mm,1.0mm,1.5mm,2.0mm,3.0mm
Roll Width: 1.0m,2.0m,3.0m,4.0m,5.8m,7m,8m
Roll Length:50m,100m,150m,200m
Geomembrana Para Estanques
Geomembrana para estanques are impermeable, durable synthetic membranes engineered as the definitive barrier for critical containment applications. Manufactured from premium-grade polymers like HDPE, LLDPE, and PVC, they are designed to provide a reliable, long-term solution for controlling and isolating liquids, vapors, and gases in the most demanding environmental and industrial projects.
geomembrana para estanques
Geomembrana para estanques’ advantages
Exceptional Impermeability: Delivering an virtually impervious barrier with extremely low hydraulic conductivity, our geomembrana para estanques effectively prevent the migration of liquids and vapors, protecting soil and groundwater from contamination.
Superior Durability & Longevity: Engineered to withstand harsh environmental conditions, our products offer outstanding resistance to UV radiation, extreme temperatures, chemicals, punctures, and stress cracking, ensuring decades of reliable service life.
geomembrana para estanques
Proven Cost-Effectiveness: Offering a more efficient and reliable alternative to traditional compacted clay liners, our geomembrana para estanques reduce material usage, accelerate installation timelines, and minimize long-term maintenance costs.
Customization & Versatility: Available in a variety of thicknesses, textures (smooth or textured for increased friction), and formulations (HDPE, LLDPE, LDPE, PVC) to meet the specific demands of any project, from municipal ponds to aggressive chemical containment.
Geomembrana Para Estanques
|
Item
|
Index
|
||||||||
|
Thickness (mm)
|
0.30
|
0.50
|
0.75
|
1.00
|
1.25
|
1.50
|
2.00
|
2.50
|
3.00
|
|
Density ( g/cm3)
|
≧0.940
|
||||||||
|
Tensile yield strength (N/mm)
|
≧4
|
≧7
|
≧10
|
≧13
|
≧16
|
≧20
|
≧26
|
≧33
|
≧40
|
|
Tensile fracture strength (N/mm)
|
≧6
|
≧10
|
≧15
|
≧20
|
≧25
|
≧30
|
≧40
|
≧50
|
≧60
|
|
Elongation at yield (%)
|
_
|
_
|
_
|
≧11
|
|||||
|
Elongation at break (%)
|
≧600
|
||||||||
|
Right-angle tear load (N)
|
≧34
|
≧56
|
≧84
|
≧115
|
≧140
|
≧170
|
≧225
|
≧280
|
≧340
|
|
Puncture strength (N)
|
≧72
|
≧120
|
≧180
|
≧240
|
≧300
|
≧360
|
≧480
|
≧600
|
≧720
|
|
Carbon black content (%)
|
2.0~3.0
|
||||||||
Geomembrana Para Estanques’ Applications
Environmental Containment:
Landfill Liners and Caps (primary and secondary)
Leachate Ponds and Evaporation Ponds
Wastewater Treatment Lagoons
Potable Water Reservoirs
Mining & Industrial:
Heap Leach Pads
Tailings Impoundments
Secondary Containment for Fuel and Chemical Storage
Water & Aquaculture:
Canal Linings for Water Conservation
Decorative and Fire Protection Ponds
Liners for Shrimp and Fish Farms
Civil Engineering:
Tunnel and Underground Waterproofing
Vapor Barriers beneath slabs
geomembrana para estanques
geomembrana para estanques
geomembrana para estanques
geomembrana para estanques
Geomembrana Para Estanques
Mine tailing disposal is one of the most important environmental issues for any mining project. To control the release of tailing materials, which are the waste product left over from a mineral-processing plant, a tailing dam or pond is created to contain the waste. In this case, geomembranes are used to protect the environment and prevent contamination of soils and groundwater tables.
As a waterproofing liner, HDPE membrane is favored over other materials for its modest economic and operational advantage. Economically, HDPE membrane is superior thanks to its relatively straight forward manufacturing process, which has driven up supply and kept prices low in contrast to other kinds of geomembranes. Furthermore, hdpe geomembrane is a very stable polyolefin that is chemically inert and able to maintain long-term integrity and durability. These properties make the HDPE membrane a popular choice to waterproof and mining, landfill and other containment applications.
