China HDPE Geomembrane Factory

100% virgin raw material

ASTM standard

Any sizes as customer requested

Multiple application

E-mail: [email protected]

Tel:0086 18253870001

REQUEST QUOTE WHATSAPP

Description

Smooth geomembranes manufactured from quality high density polyethylene resins(HDPE) that comply with the most rigorous requirements established for their use. The 0.5 mm hdpe geomembrane is popular thickness,its widely used in aquaculture project,fish pond,shrimp pond and irrigation pond. Smooth geomembrane, is a geosynthetic material with a flat and smooth appearance.

china hdpe geomembrane factory

Geomembranes are impermeable synthetic membranes widely used in environmental and geotechnical engineering for containment and barrier applications. Typically made from materials like HDPE (High-Density Polyethylene), LLDPE (Linear Low-Density Polyethylene), PVC, or EPDM, they provide excellent resistance to chemicals, UV radiation, and punctures.
Common applications include landfill liners, mining leachate ponds, water reservoirs, and wastewater treatment facilities. Their durability, flexibility, and low permeability make them essential for preventing fluid migration and protecting soil and groundwater from contamination.

china hdpe geomembrane factory

Specifications

China HDPE Geomembrane Factory

Item	HDPE Geomembrane Technical Data
Thickness (mm)	0.30	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
Density ( g/cm3)	≧0.940
Tensile yield strength (N/mm)	≧4	≧7	≧10	≧13	≧16	≧20	≧26	≧33	≧40
Tensile fracture strength (N/mm)	≧6	≧10	≧15	≧20	≧25	≧30	≧40	≧50	≧60
elongation at yield (%)	_	_	_	≧11
elongation at break (%)	≧600
Right-angle tear load (N)	≧34	≧56	≧84	≧115	≧140	≧170	≧225	≧280	≧340
Puncture strength (N)	≧72	≧120	≧180	≧240	≧300	≧360	≧480	≧600	≧720
Carbon black content (%)	2.0~3.0

Applications

Aquaculture
Sea water or fresh water shrimp or fish farming pond.

Mining
Washing Pond, heap leaching pond, ash field, dissolving and sedimentation Pond, tailing bottom lining etc.

Landscaping
River, Reservoir, artificial lake, golf course pond waterproofing, artificial grass waterproof and moisture-proof.

Salt industry
Salt farm crystallization Pond, collection Pond.

Solid or liquid waste treatment
Landfill, waste water plant, industrial or hospital waste treatment site anti-seepage

Water conservancy Project: River
Embankment, lake Dam, tailing dam, sewage dam and reservoir channel, Vertical wall, slope protection seepage contra

Related Videos

Product Feature

Excellent Waterproof Performance:
Smooth geomembrane has extremely low permeability, which can effectively prevent the penetration of water and other liquids,ensuring the stability and safety of engineering structures.
Good Chemical Stability:
The material can withstand the erosion of a variety of chemical substances,including acids, alkalis, salts, etc., and is suitable for various complex environments.
High Strength And Toughness:
Smooth geomembrane has high tensile strength and elongation at break, can withstand large stress and deformation,and is not easy to break.
Aging Resistance:
Due to the addition of auxiliary materials such as anti-aging agents,Smooth geomembrane can maintain its stable performance for a long time and extend its service life.
