Road Construction Geogrid
Type: Uniaxial Geogrid, Biaxial Geogrid, Triaxial Geogrid
Key Properties: High strength in one primary direction; Balanced strength in both longitudinal and transverse directions; Multi-directional reinforcement with enhanced stability
Common Uses: Retaining walls, steep slopes, embankments;Road bases, parking areas, foundation mats; High-traffic pavements, airports, railway beds
Road Construction Geogrid
The road construction geogrid made from high-density polyethylene (HDPE) or polypropylene (PP), it provides tensile strength to soil masses, creating a composite material with improved load-bearing capacity and long-term performance. Ideal for civil, geotechnical, and construction applications where ground improvement is essential.
Road Construction Geogrid
The Features of Road Construction Geogrid
High Tensile Strength: Distributes loads over a wider area, reducing stress on subgrades and increasing structural integrity.
Durable & Resistant: UV-stabilized and chemically inert, ensuring long-term performance in harsh environmental conditions.
Optimal Soil Interlock: Aperture geometry is designed to effectively engage with soil and aggregate for maximum reinforcement efficiency.
Road construction geogrid
Flame retardant aditives
Light weight, high tensile strength, high modulus, low elongation and good toughness. Corrosion resistance, no long-term creep, long life span.
Corrosion resistance,aging resistance
Good physical and chemical stability and good thermal stability.Resistant to fatigue cracking, high-temperature track and low temperature shrinkage cracking. Delaying and decreasing crack reflection.
Road Construction Geogrid’s Specifications
|
Steel Plastic Geogrid Specification
|
|||||||
|
Performance/Specification
|
TGDC30
|
TGDC50
|
TGDC80
|
TGDC100
|
TGDC120
|
TGDC150
|
|
|
Vertically Limited Rally (KN/m)>=
|
30
|
50
|
80
|
100
|
120
|
150
|
|
|
Vertically Limited elongation ratio(%)<=
|
3
|
3
|
3
|
3
|
3
|
3
|
|
|
Elongation at a% of the rally (KN/m)>=
|
23
|
38
|
63
|
81
|
98
|
125
|
|
|
Width(m)
|
6m
|
||||||
Road Construction Geogrid’s Applications
Civil & Infrastructure
Road and railway base reinforcement
Retaining walls and steep slopes
Foundation support for embankments and structures
Environmental & Landscaping
Erosion control on slopes and channels
Landfill liner support and cover systems
Reinforcement for green roofs and vegetated surfaces
Commercial & Industrial
Parking lots and storage yards
Port and airport pavements
Reinforcement under heavy industrial floors
Road construction geogrid
Road construction geogrid
Road construction geogrid
Road construction geogrid
Road construction geogrid
The road construction geogrid are manufactured using advanced polymer extrusion and stretching technology, ensuring consistent quality and performance. With a focus on innovation and sustainability, we help you build stronger, longer-lasting, and more economical infrastructure.
