Geogrid Fabric Retaining Walls
Material: PET,PP,Fiberglass,Steel plastic,Fiber plastic Geogrid
Tensile Strength: 20,30,50,80,100,150,200,400,500,600,800,1200kN/m
Roll Width: 1m,2m,3m,4m,5m,6m
Roll Length: 50m,100m,200m
Colors: Black
Geogrid Fabric Retaining Walls
Manufactured from premium polymers such as High-Density Polyethylene (HDPE), Linear Low-Density Polyethylene (LLDPE), and Polyvinyl Chloride (PVC), our geogrid fabric retaining walls provide a reliable, factory-controlled solution for critical containment projects worldwide. Supplied in wide panels and long lengths, they minimize field seams, reduce installation time, and enhance overall system integrity.
Geogrid Fabric Retaining Walls
The Key Features of Geogrid Fabric Retaining Walls
High Tensile Strength & Stiffness: Provides significant tensile strength at low strain, effectively distributing loads and reducing stress on the underlying soil.
Optimal Soil Interaction: The large apertures (openings) allow for full interlock with soil and aggregate particles, creating a mechanically stabilized zone.
Excellent Durability: Resistant to chemical and biological degradation, UV radiation, and installation damage, ensuring long-term performance.
Geogrid Fabric Retaining Walls
Reduced Material & Construction Costs: Enables the use of lower-quality, on-site fill materials, reduces required fill thickness, and allows for steeper slope construction.
Versatility: Available in uniaxial, biaxial, and triaxial orientations to address different stress conditions (primary in one direction or multiple directions).
High vertical and horizontal tensile strength, low unit extension, high flexibility, and favorable high and low temperature resistance. The products after surface covering own the favorable property of alkali resistance and aging resistance.
Geogrid Fabric Retaining Walls’s Specifications
|
Steel Plastic Geogrid Specification
|
|||||||
|
Performance/Specification
|
TGDC30
|
TGDC50
|
TGDC80
|
TGDC100
|
TGDC120
|
TGDC150
|
|
|
Vertically Limited Rally (KN/m)>=
|
30
|
50
|
80
|
100
|
120
|
150
|
|
|
Vertically Limited elongation ratio(%)<=
|
3
|
3
|
3
|
3
|
3
|
3
|
|
|
Elongation at a% of the rally (KN/m)>=
|
23
|
38
|
63
|
81
|
98
|
125
|
|
|
Width(m)
|
6m
|
||||||
Geogrid Fabric Retaining Walls’s Applications
Road & Railway Construction: Base and subgrade stabilization.
Retaining Structures: Mechanically Stabilized Earth (MSE) walls, reinforced slopes.
Landfills: Reinforcement of liner systems and final cover systems.
Working Platforms: Stabilization of soft ground for construction access.
Erosion Control: Reinforcement in channel protections and shorelines.
Geogrid Fabric Retaining Walls
Geogrid Fabric Retaining Walls
Geogrid Fabric Retaining Walls
Geogrid Fabric Retaining Walls
Improve the stability and bearing capacity of the roadbed, and extend the service life
Provent the deformation and cracking of subguarde caused by the loss of subgrade materials
High strength,good fiexibility,anti-aging,resisting acid and alkaline
The filling capacity of retaining wall is improved, the earth pressure of retaining wall is reduced,the cost is saved, the service life is extended, and the maintenance cost is reduced
