Geobags Meaning
Material: PP(Ploypropylene)
Geobags Weight: 285gms/Customized
Colors: Black, Sand, Customized
Description
Geobags Meaning
Geotextile geobag meaning is one kind of bag with pipe shape, woven with polypropylene yarn with filter structure, the principle of action is in the process of underwater dredging will be polymer flocculant a certain proportion of the solution into the mud, fully mixed into the geobag , after pressure filtration dehydration and consolidation, so as to reduce the volume of sludge and solidifying effect.
geobags meaning
Geobags Meaning’s Advantages
High Tensile Strength: Ensures durability and reliability in various applications.
PP Woven Geotextile Material: Provides excellent tear resistance and anti-aging properties.
Customizable Dimensions: Tailored to meet specific project needs.
Simple Operation: Easy setup and use without requiring special equipment.
Cost-Effective Management: Effective for managing waste from animal feeding operations.
geobags meaning
Material & Durability
Made from UV-resistant, woven or non-woven geotextile fabric.
High tensile strength to withstand filling, placement, and hydraulic forces.
Resistant to punctures, abrasion, and chemical degradation.
Permeability
Allows water to drain out while retaining fine soil particles.
Reduces hydrostatic pressure, improving stability.
Flexibility & Adaptability
Can be custom-sized (length, width/Cir.) for different projects.
Conforms to uneven surfaces, making them ideal for erosion control.
Specifications
Geobags Meaning’s Specifications
| UNIT | TEST STANDARD | UNIT TEST STANDARD | ||||||||||
| DK70×95B | DK70×95 | DK120×120 | DK200×200 | DK200×200B | DK380 | DK580 | DK380PPi | DK580PPi | ||||
| Breaking strength | vertical | KN/m | ISO 10319-2015 |
85 | 85 | 130 | 220 | 220 | 70 | 85 | 70 | 85 |
| weft | KN/m | 105 | 115 | 120 | 200 | 210 | 60 | 80 | 80 | 105 | ||
| Elongation at break | vertical | % | 13 | 13 | 12 | 13 | 13 | 12 | 12 | 13 | 13 | |
| weft | % | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 9 | 9 | ||
| Breaking strength at 2% elongation | vertical | KN/m | 14 | 14 | 20 | 12 | 10 | 14 | 15 | 9 | 8 | |
| Breaking strength at 5% elongation | weft | KN/m | 38 | 38 | 80 | 95 | 88 | 38 | 42 | 26.5 | 21 | |
| Weight | g/m2 | 430 | 450 | 540 | 850 | 870 | 285 | 385 | 340 | 420 | ||
| Joint tensile strength | KN/m | ISO 10321-2008 | 70 | 90 | 100 | 170 | 180 | |||||
| CBR Puncture Strength（CBR） | KN |
ASTM D6241 |
8 | 9 | 15 | 20 | 23 | 7 | 10 | 8.5 | 10 | |
| Dynamic perforation | mm | 10 | 8 | 10 | 8 | 8 | ||||||
| Equivalent aperture（O90） | mm |
ISO 12956 |
0.5 | 0.45 | 0.45 | 0.45 | 0.35 | 0.48 | 0.45 | 0.48 | 0.47 | |
| Permeability（Q50） | L/m2/s |
ISO 12956 |
50 | 35 | 14 | 18 | 15 | 35 | 42 | 58 | 58 | |
| UV Resistance（500 hours strong preservation rate） | % | ASTM D4355-2014 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | |
Applications
Geobags Meaning
Palm oil filtration
The Geobag dewatering operation is simple and does not require special equipment that the POME treatment facility is not already using.
Coastal Protection
Development activities in the shoreline, alongside erosion, marine storms may lead to destructive effects on objects.
Sludge Dewatering
For smaller applications, geotextile tubes dewatering sludge produced in wastewater treatment process.
Mining, Mineral Processing
Mine tailings,coal sludge can be managed, handled cost effectively with geotextile tubes dewatering technology.
Environmental Remediation
In many cases, sediments pose significant environmental hazards, and remediation is a difficult expensive task.
Agriculture
With Geobag dewatering technology, you can effectively manage waste from animal feeding operations while also controlling odor.
geobags meaning
geobags meaning
geobags meaning
geobags meaning
Related Videos
Geobags Meaning
The volume of sludge can be reduced by more than 90%, and it contains a higher proportion of solid content, making it easier to remove and process. Separates solids from sludge or dredged material.
The embankment core filling geobag breakwater is a breakwater made of new materials. It forms a kind of breakwater by filling the geobag with sea sand. Not only saves the construction cost of the breakwater, but also makes better use of environmental resources, and can well meet the construction and functional requiremenrs of the breakwater. Acts as submerged barriers.
Geotextile tube bag dewatering technology can dehydrate the bottom mud gathered in river, bays seaports, wharves, ports and docks to project the environment. Creates barriers for sediment control.
geobags meaning
geobags meaning
Related Products
View All
Geobag Dewatering
Geobag Dewatering dewatering filling with Environmental Sediments, Industrial Sludge, Sewage, Mining Residuals and etc. There are too many sediments carried by rivers and streams into down gradient harbors, estuaries and deltas every year in the world. The dredging, a safe and efficient strategies is necessary, the geotextile dewatering tube not only to dewater the dredged material while under pressure but also to decontaminate them is the unltimate goal. By dewatering we mean to decrease the water content of slurried material to a point where geotextile bags handling of the sediments by standard earth moving equipment is possible.
View product >
Geobag Sludge Dewatering
After the solids have fully solidified or fulfilled the minimal criteria for transportation, the dewatered materials can be disposed of in a variety of ways. Geotube dewatering containers are constructed into tubular, sack like, or other shapes with loading ports or other arrangements for site filling utilizing high resilience and grade seaming processes.
View product >
Geotextile Dewatering Tubes
Geotextile Dewatering Tubes are used in a wide range of applications to dewater sediment laden water retaining the soil particles in the tubes allowing the clean water to filter through the tubes. The filtrate water is often returned into the source pond or released depending on the consent conditions.
View product >
Nonwoven Geotextile Geobag
Encapsulating or wrapping sand into geotextile units provides a variety of flexible, economical and ecological coastal applications. Especially at sandy beaches, the use of rocks, steel and concrete as "hard coastal structures" should be avoided where possible.Geobag made of needle-punched nonwovens offer more advantages as 'soft rock structures'.as flexible construction elements geobag behave advantageously with respect to cyclical hydrodynamic loads and morphological seabed changes.
View product >
Geobag For Shoreline Protection
Geobag is a tubular bag made of high-strength geotextile, High-strength polypropylene (PP) or polyester (PET) geotextile, with good tensile, tear and UV resistance.
View product >
Geobag for Filtration
Geobag is a tubular bag made of high-strength geotextile, which is widely used in water conservancy, environmental protection, marine engineering and other fields.
1. Material
High-strength geotextile: usually made of high-strength synthetic fibers such as polypropylene (PP) or polyester (PET), with good tensile, tear and UV resistance.
2. Geobag geotextile tube of Structure
Tubular design: cylindrical, both ends can be closed, and the length and diameter are customized according to project requirements.
Multi-layer structure: Some geotextile tube bags adopt multi-layer design to enhance their strength and filtration performance.
3. Geobag of Function
Filtration and drainage: allows water to pass through while intercepting solid particles, often used for sludge dewatering.
Protection and reinforcement: used for protection and reinforcement of projects such as dams and coastlines.
Environmental protection and ecological restoration: used for pollution control and ecological restoration, such as river dredging, wetland restoration, etc.
View product >
